EMX-CDD Quick Installation Guide

EMX-CDD Quick Installation Guide 11

2.3.7 Jumper for inverter power (ADJ_PWR1)

* Default

5V*

5V

0

PIN

Define

Max current

1-2

5V

1A

3-4

5V

1A

5-6

0

1A

2.3.8 Serial port 1~6

– RI, USE JC1~6 PIN 9 selector (JC11~16)

* Default

RI*

USE JC1_JC6

PIN Option

Define

CLOSE

RI

OPEN

USE JC_JC6

JC
11

JC1

2

JC13

JC14

JC1

5

JC1

6
