COM6

Signal

PIN PIN

Signal

NDCD6-

1

2

NRXD6-

NTXD6-

3

4

NDTR6-

GND

5

6

NDSR6-

NRTS6-

7

8

NCTS6-

NRI6-

9

10

NC

2.6.6

Front Panel Audio Header (F_AUDIO)

F_AUDIO

Signal

PIN PIN

Signal

MIC_L

1

2

AGND

MIC_R

3

4

-ACZ_DET

HPOUT_R

5

6

SRTN1

FAUDIO_JD

7

HPOUT_L

9

10

SRTN2
