User ’s Manual
EMX-CDV User ’s Manual 55
3.6.3.1 Intel IGD Configuration
Item Options Description
IGFX – Boot Type
VBIOS Default[Default]
CRT
EFP
CRT+EFP
Select the Video Device which will be
activated during POST. This has no
effect if external graphics present.
Fixed Graphics Memory Size
128MB[Default]
256MB
Configure Fixed Graphics Memory
Size.
LVDS Backlight PWM
0% [Default]
25%
50%
75%
100%
LVDS Backlight PWM Configuration.
Panel ID
1024x768 1ch 24bit[Default]
800x600 1ch
1024x768 1ch 18bit
1024x600 1ch
1280x800 1ch
1920x1200 2ch
640x480 1ch
800x480 1ch
1280x1024 2ch
1440x900 2ch
1600x1200 2ch
1366x768 1ch
1920x1080 2ch
1680x1050 2ch
Panel ID.
