EMX-CDV
12 EMX-CDV User ’s Manual
1.4 System Specifications
System
CPU Onboard Intel® Atom™ D2550(N2800/N2600 for Option)
BIOS AMI 16Mb SPI BIOS
System Chipset Intel® ICH10R
I/O Chip ITE8783+ FINTEK F81214
System Memory
2x 204-pin DDR3 SODIMM, up to 4GB (N2600 support 1 x DDR3
SODIMM only)
Watchdog Timer H/W Reset : 1 to 255 sec/min per step
H/W Status Monitor
Monitoring temperature, voltage, and cooling fan
status. Auto throttling control when CPU overheats
TPM Infineon TPM1.2 SLB9635 (Optional)
Expansion 1x PCI
2 x mini-PCI-E connectors
SSD 1 x mSATA supports on the 2
nd
mini-PCIe (Optional)
Smart Fan Control Yes
Display
Chipset Cedarview Integrated graphics
Dual Display LVDS+VGA, VGA+HDMI, HDMI+LVDS
VGA
HDMI
Max resolution: 1920 x 1200
Max resolution: 1920 x 1200
LVDS
eDP to LVDS translator, Dual channel 18/24 bit
Max resolution: 1920 x 1080
LVDS Backlight Yes, through internal LVDS Backlight Connector
Audio
Audio Codec Azalia Realtek ALC269
Audio Interface Mic-In, Line-In and Line-Out, speaker out
Audio Amplifier(W) Build-in 2W Audio amplifier on chip
Ethernet
Chipset 2 x Realtek 8111E
Ethernet Interface 10/100/1000 Gigabit Ethernet Compatible
I/O
MIO
2 External(COM1, RS-232/422/485; COM2, RS-232), 4 Internal
(COM3, RS-232 with 5V/12V selected by jumper, COM4~6, RS-232),
4 SATA II, 1 HDMI, 1 VGA, 1 LVDS, 2 LAN, 1 PS/2
USB 7 USB 2.0 (4 Rear, 3 Internal)
