ECM-VX900
ECM-VX900 User ’s Manual 47
3.6.2.3 Super IO Configuration
Use the Super IO Configuration menu for serial ports.
Item Options Description
Serial Port1 Address [3F8/IRQ4]
Disabled
3F8/IRQ4 (D EFAULT)
3E8/IRQ4
2E8/IRQ3
Use the Serial Port1 Address option to select
the Serial Port 1 base address.
Serial Port2 Address [2F8/IRQ3]
Disabled
2F8/IRQ3 (D EFAULT)
3E8/IRQ4
2E8/IRQ3
Use the Serial Port2 Address option to select
the Serial Port 2 base address.
Serial Port 2 Type [232]
232
422
485 Use the Serial Port2 Type option to select the
Serial Port 2 base type.
