ECM-QB User ’s Manual
ECM-QB User ’s Manual 45
Item Option Description
Serial Port
Enabled,
Disabled
Use the Serial port option to
enable or disable the serial
port.
Change Settings
IO=3F8h; IRQ=4,
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Use the change Settings
option to change the serial port
IO port address and interrupt
address.
3.6.2.6.2 Serial Port 1 Configuration
Item Option Description
Serial Port
Enabled,
Disabled Use the Serial port option to
enable or disable the serial
port.
Change Settings
IO=3F8h; IRQ=4,
IO=3F8h;
IRQ=3,4,5,6,7,10,11,12
IO=2F8h;
IRQ=3,4,5,6,7,10,11,12
IO=3E8h;
IRQ=3,4,5,6,7,10,11,12
IO=2E8h;
IRQ=3,4,5,6,7,10,11,12
Use the change Settings
option to change the serial port
IO port address and interrupt
address.
