ECM-QB User ’s Manual
12 ECM-QB User ’s Manual
1.5 System Specifications
System
CPU Intel Tunnel Creek LPIA Core 0.6GHz, 1.0GHz, 1.3GHz, 1.6GHz
BIOS AMI 16Mbit Flash BIOS
System Chipset Intel Tunnel Creek + Intel Topcliff
I/O Chip Nuvoton W83627DHG-P
System Memory Onboard DDR2 1GB Memory
SSD 1 x CF Socket, 1 x MicroSD
Watchdog Timer Reset: 1sec.~ 65535sec./min. and 1sec. or 1min./step
H/W Status
Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto trotting control
when CPU overheats
Expansion 1 PCIe Mini Card slot, 1 LPC
I/O
MIO 2 x SATA, 3 x RS-232, 1 x RS-422, 1 x RS-485 , 1x CAN
USB 4 x USB 2.0
IrDA N/A
DIO 8-bit GPI and 8-bit GPO
Display
Chipset Intel Tunnel Creek Integrated
Resolution
CRT mode: 1280 x 1024 @ 85 Hz (by Chrontel CH7317B)
LCD/Simultaneous mode: 1280 x 768 @ 60 Hz
Multiple Display CRT+ LVDS
LCD Interface Single-Channel 18/24-bit LVDS
TV-out N/A
Audio
AC97 Codec Realtek ALC892 support 7.1CH audio
Audio Interface Mic in, Line in, Line out
Ethernet
LAN Chip 2 x Intel 82574L PCI-E Gigabit LAN
Ethernet Interface 1000Base-Tx Gigabit Ethernet compatible
