ECM-QB User

’s Manual

26 ECM-QB User

’s Manual

2.4.10

USB 2 & 3 connector (CN6)

Signal

PIN PIN

Signa

VCC_USB23

1

2

GND

USB2_N

3

4

GND

USB2_P

5

6

USB3_P

GND

7

8

USB3_N

GND

9

10

VCC_USB23

2.4.11

LPC connector (CN7)

Signal

PIN PIN

Signal

AD0

1

2

V3P3_S

AD1

3

4

BUF_RESET#

AD2

5

6

LPC_FRAME#

AD3

7

8

LPC1_PCI_CLK

SERIRQ

9

10

GND

VCC_5S

11

12

GND

VCC5V_A

13

14

V3P3_S
