AVALON RF, INC. Page 5
GS Series User’s Guide & Operating Manual
2. Specifications
2.1 Electrical Specifications.
Frequency Range:
GS-S 2300 – 2500 MHz (standard)
GS-L 1700 – 1850 MHz (standard)
Tuning:
16 channels (determined by user defined
frequencies) via rotary switch
RF Sensitivity:
typ better than - 84 dBm
Bandwidth:
16 MHz
Antennas:
1 x 5 dBi omni antenna (detachable)
GS-S-20 1 x 20 dBi flat panel (HBW= 15; VBW= 16) on front
face
GS-S-15 1 x 15 dBi flat panel (HBW= 20; VBW= 33) on front
face
GS-L-18 1 x 18 dBi flat panel (HBW= 20; VBW= 20) on front
face
GS-L-13 1 x 13 dBi flat panel (HBW= 30; VBW= 30) on front
face
Video Output:
NTSC or PAL (depending on system ordered)
Video level:
1 Vp-p into 75 ohm, Negative Sync Tip, dc restored
to ground.
Telemetry Downlink (optional)
Telemetry output:
RS232 compatible signal levels with 8 data bits, No
Parity, 1 stop bit
Baud Rate:
4800 Baud
