english
5
Koko Xtra 2.0
1. TECHNICAL DATA
As a stove of construction type 1, it is possible to
connect it to the chimney of an existing other stove or
another hearth for solid fuels, as long as the chimney
dimensioning complies with DIN 4705, Part 3.
TECHNICAL DATA
Height
1196 mm
Width
546 mm
Depth
445 mm
Weight
253 kg
Flue pipe outlet diameter
150 mm
Nominal thermal output (EN
6 kW
Maximum thermal capacity
8 kW
Smallest heating capacity
3,5 kW
Room heating capacity (depending on
building insulation)
65 – 165
m³
Exhaust values for multiple use of the chimney in
accordance with DIN 4705, Part 3 and for the
calculation of the chimney measurements in
accordance with DIN 4705, Part 2
Fluegas mass flow
closed
4,43 g/s
Fluegas temperature
closed
331 °C
Minimum feed pressure
Nominal thermal output
closed
10 Pa
at 0.8 times
n. ther. outp.
8 Pa
2. IMPORTANT INFORMATION
The installation and operation information given here is of
general nature
. National and European standards, local
and building regulations as well as fire prevention laws
must be observed during the operation of the stove.
General safety instructions for the
operation of your stove
•
Thoroughly read the entire manual before starting up
your stove and observe the caution notices.
•
Your heating unit may not be moved without
approved means of transport with sufficient load-bearing
capacity.
•
Your heating unit is not suitable to be used as a
stand or as a ladder.
•
Please keep in mind that your
stove’s surface heats up
considerably during operation. We
therefore recommend wearing a
safety mitten when operating your
stove.
• Attention – stove varnish is no rust prevention!
•
Make your children aware of this particular
danger and keep them at a distance from the heating unit
whenever it is in operation.
•
Only burn approved fuels and materials listed in the
chapter “Clean Burning”.
•
The burning or placing of flammable or explosive
materials, like empty spray cans and such like into the
firebox as well as the storage of such materials in the
immediate vicinity of your heating unit is strictly forbidden
due the danger of explosion.
•
Do not wear loose or flammable clothing when
adding fuel to the fire.
•
Placing non-heat-resistant objects on the heating
unit or in the vicinity of the heating unit is forbidden.
•
Do not lay laundry onto the stove for drying. Laundry
hung up to dry must be kept at a safe distance from the
stove because of the danger of fire.
•
The woodstove Koko Xtra 2.0 is not suitable for long
term heating.
•
During the operation of your heating unit it is
forbidden to use flammable or explosive materials in the
same or an adjacent room to the one in which your
heating unit is located
Setting up your stove
Required safety distances
(Minimum
distances – see name plate - in Fig. 2)
a > 1200 mm
b > 540 mm
c > 180 mm
(a – toward the front in the radiated area)
(b – to the side)
(c – to the back)
Make sure that the room in which the stove is set up has
at least one door or window into the outside or is directly
adjacent to such a room. Other fireplaces and extractor
hoods must not be operated in the same room as the
stove
.
Floor load capacity
Make sure that the load capacity of the supporting
construction is sufficient to carry the weight of the entire
unit
, before the heating unit is installed.
