Austin Hughes OP-W27 - Manual (Page 24)

UM-UV-621-W27-Q215V1 www.austin-hughes.com
■
Dimension will be changed if Multi-touch required
■
USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
■
For detailed information, please refer to the attached CD disc
■
As the touchscreen unit is not made of toughened glass, please handle it carefully
Model TPC-27 Multi-touch
Technology Projected Capacitive
Touch Point 10
Input Type Finger or Capacitive Stylus
Resolution 2048 x 2048
Touch Point Accuracy ± 25 mm offset
Response Speed Max. 20 ms
Activation Force ≤ 10 g
Surface Hardness 7H
Light Transmission ≥ 88%
Haze ≤ 2%
Durability > 100 million touches
Top Layer 1.8 mm Tempered Glass
Bottom Layer Film
Thickness 2.4 mm
Connector USB Type A
Compatibility Windows 7
< 4.4 > Options : Touchscreen & driver
W27" USB Touchscreen Specifi cation
P.20
Connect the USB cable from the USB port on the LCD to a computer. The touch screen supports
easy Plug-and-Play operations. There is no need to install additional drivers on the computer.
TPC-27 Driver
VGA DVI-D HDMI S-Video Power R C A Audio
in
Audio
out
USB Touchscreen
