Austin Hughes OP-W27 - Manual (Page 11)

UM-UV-621-W27-Q215V1 www.austin-hughes.com
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
OP-W27
696 x 62 x 435 mm
27.4 x 2.4 x 17.1 inch
785 x 175 x 527 mm
30.9 x 6.9 x 20.7 inch
12.7 kg
27.9 lbs
16.3 kg
35.9 lbs
27” FHD LCD Display
Front view
Rear view
Rear case
LCD panel
Universal open frame mounting
Audio speaker, pair
LCD membrane
Extended remote sensor membrane cable
( 66cm from AD board to sensor end )
1
2
3
4
5
Top view
6
6
< 2.2 > Structure Diagram - OP-W27
OP-W27
P.7
4
1
2
5
3
