UM-UV-621-HW42-Q215V1 www.austin-hughes.com
W42” High Brightness LCD Display
Model TPC-42 Multi-touch
Technology Projected Capacitive
Touch Point 10
Input Type Finger or Capacitive Stylus
Resolution 2048 x 2048
Touch Point Accuracy ± 25 mm offset
Response Speed Max. 20 ms
Activation Force ≤ 10 g
Surface Hardness 7H
Light Transmission ≥ 88%
Haze ≤ 2%
Durability > 100 million touches
Top Layer 2.8 mm Tempered Glass
Bottom Layer Film
Thickness 3.2 mm
Connector USB Type A
Compatibility Windows 7
HW42" USB Touchscreen Specifi cation
P.20
< 4.4 > Options : Touchscreen & driver
VGA DVI-D HDMI S-Video Power R C A Audio
in
Audio
out
USB Touchscreen
■
Dimension will be changed if Multi-touch required
■
USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
■
For detailed information, please refer to the attached CD disc
■
As the touchscreen unit is not made of toughened glass, please handle it carefully
