Rear case
LCD panel
Audio speaker ( for HDMI, Audio or TV option )
Universal open frame mounting
LCD membrane
Extended remote sensor membrane cable
( 66cm from AD board to sensor end )
1
2
3
4
5
6
6
1
2
3
4
5
< 2.2 > Structure Diagram - HOP-17
Front view
1
2
Rear view
5
OP-17
4
3
17” High Brightness LCD Display
P.7
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
HOP-17
436 x 58.2 x 353.6 mm
17.2 x 2.3 x 13.9 inch
615 x 113 x 523 mm
24.2 x 4.4 x 20.6 inch
4.9 kg
10.8 lbs
7.5 kg
16.5 lbs
