Service parts list – Daewoo DSC-3270E User Manual
Page 41
40
LOC
PART-CODE
PART-NAME
PART-DESC
LOC
PART-CODE
PART-NAME
PART-DESC
Service Parts List
RCD32
HRFT161JCA
R CHIP
1/10 160 OHM J 2012
RCD33
HRFT161JCA
R CHIP
1/10 160 OHM J 2012
RCD50
HRFT431JCA
R CHIP
1/10 430 OHM J 2012
RCD51
HRFT431JCA
R CHIP
1/10 430 OHM J 2012
RCD52
HRFT431JCA
R CHIP
1/10 430 OHM J 2012
RCD53
HRFT431JCA
R CHIP
1/10 430 OHM J 2012
RCD54
HRFT101JCA
R CHIP
1/10 100 OHM J 2012
RCD55
HRFT101JCA
R CHIP
1/10 100 OHM J 2012
RCD56
HRFT101JCA
R CHIP
1/10 100 OHM J 2012
RCD57
HRFT101JCA
R CHIP
1/10 100 OHM J 2012
RCD61
HRFT152JCA
R CHIP
1/10 1.5K OHM J 2012
RCD62
HRFT151JCA
R CHIP
1/10 150 OHM J 2012
RCD63
HRFT151JCA
R CHIP
1/10 150 OHM J 2012
RCD64
HRFT151JCA
R CHIP
1/10 150 OHM J 2012
RCD65
HRFT151JCA
R CHIP
1/10 150 OHM J 2012
RCD70
HRFT431JCA
R CHIP
1/10 430 OHM J 2012
RCD71
HRFT431JCA
R CHIP
1/10 430 OHM J 2012
RCD72
HRFT431JCA
R CHIP
1/10 430 OHM J 2012
RCD73
HRFT681JCA
R CHIP
1/10 680 OHM J 2012
RCD90
HRFT103JCA
R CHIP
1/10 10K OHM J 2012
ZZ200
PEVDJ1D018
PCB VIDEO CHIP A AS DSC-3270E
A001
4959802924
PCB VIDEO AS
143 X 246
ID01
1VPC3215CT
IC CHIP VIDEO
VPC3215C
ID02
1C1P3250AT
IC CHIP VIDEO
CIP3250A
ID03
1MSM54122Q
IC MEMORY
MSM5412222
ID04
1DDP3310BT
IC CHIP
DDP3310B
ZZ500
PEUNSWD018
PCB UNION AS
DSC-3270E
C904
CEXF2C100V
C ELECTRO
160V RSS 10MF (10X16) TP
C906
CEXF2C470V
C ELECTRO
160V RSS 47MF (13X25) TP
C915
CEXF2C100V
C ELECTRO
160V RSS 10MF (10X16) TP
C923
CMYL2G104J
C MYLAR
400V MEU 0.1MF J
C924
CEXF2E100V
C ELECTRO
250V RSS 10MF (10X20) TP
C927
CEXF1C102V
C ELECTRO
16V RSS 1000MF (10X20) TP
C928
CEXF1H221V
C ELECTRO
50V RSS 220MF (10X16) TP
C932
CMYL2G104J
C MYLAR
400V MEU 0.1MF J
C942
CEXF2E479V
C ELECTRO
250V RSS 4.7MF (10X16)TP
C946
4SG0D00103
SPARK GAP
S-23 900V-1.5KV
C947
4SG0D00103
SPARK GAP
S-23 900V-1.5KV
C948
4SG0D00103
SPARK GAP
S-23 900V-1.5KV
C949
CH1HFE102M
C CERA AC
4.0KV 1000PF E DG
C951
CMYL2G104J
C MYLAR
400V MEU 0.1MF J
DY1
DH1L25RS—
LED (RED)
HI-L25RS
DY2
DH1L25RS—
LED (RED)
HI-L25RS
DY3
DH1L25RGD-
“LED (R,G-3 COLOR)”
HI-L25RGD
DY4
DH1L25RGD-
“LED (R,G-3 COLOR)”
HI-L25RGD
IY1
1SR9HP——
IC PREAMP
SR-9HP
I901
1TDA6111Q-
IC AMP VIDEO
TDA6111Q
I901A
4857018902
HEAT SINK
A1050P-H24
I901B
7174300811
SCREW TAPPTITE
TT2 RND 3X8 MFZN
I902
1TDA6111Q-
IC AMP VIDEO
TDA6111Q
I902A
4857018902
HEAT SINK
A1050P-H24
I902B
7174300811
SCREW TAPPTITE
TT2 RND 3X8 MFZN
I903
1TDA6111Q-
IC AMP VIDEO
TDA6111Q
I903A
4857018902
HEAT SINK
A1050P-H24
I903B
7174300811
SCREW TAPPTITE
TT2 RND 3X8 MFZN
JZ1
4859105240
JACK PHONO
LGT1516-0100
JZ2
4859105340
JACK S-VHS
YKF51-5359
JZ3
4859105450
JACK PIN BOARD
YSC03P-4120-9S
M321
4953200600
BRKT POWER
EGI T1.2
M321A
7063300612
SCREW MACHINE
M/C BIN 3X6 MFZN BK
M491
4954901100
BUTTIN CH
ABS PAINT
M551
4955500100
DECO SENSOR
PMMA MILKY
M552
4957900400
TUBE
GSHS-1625 T0.3
PA11V
4950706022
CONNECTOR
YH025-06+YST250+ULW=600
PA903
4950704016
CONNECTOR
YH025-04+YST250+ULW=450
PA905
4950703014
CONNECTOR
EFR-03+SHE001T-P0.6+W=200
PA910
4950705009
CONNECTOR
YH025-05+YST250+ULW=400
PA911
4950703015
CONNECTOR
YH025-03+YST250+ULW=600
PA912
4950705008
CONNECTOR
YH025-05+YST250+ULW=500
PS801
4950702004
CONNECTOR
YFH800-02+YDT236+ULW=1000
PWU1
4859236820
CONN WAFER
YAW025-11
PW998
4859235120
CONN WAFER
YW025-08
PW999
4859238620
CONN WAFER
YPW500-02
Q908
TKTA1659Y-
TR
KTA 1659-Y
Q908A
4857026901
HEAT SINK
AL EX BK
Q908B
7174300811
SCREW TAPPTITE
TT2 RND 3X8 MFZN
Q909
TKTC4370Y-
TR
KTC 4370-Y
Q909A
4857026900
HEAT SINK
AL EX
Q909B
7174300811
SCREW TAPPTITE
TT2 RND 3X8 MFZN
R923
RS02Y221J-
R M-OXIDE FILM
2W 220 OHM J
R939
RS02Y683JS
R M-OXIDE FILM
2W 68K OHM J SMALL
R940
RS02Y683JS
R M-OXIDE FILM
2W 68K OHM J SMALL
R941
RS02Y683JS
R M-OXIDE FILM
2W 68K OHM J SMALL
SCT1
4859303730
SOCKET CRT
ISD-07S
SW801
5S40000003
SW POWER PUSH
SS-160-7-G
ZZ200
PEUNJRD018
PCB UNION RADIAL AS DSC-3270E
CY1
CEXF1H108V
C ELECTRO
50V RSS 0.1MF (5X11) TP
CY2
CCXF1H103Z
C CERA
50V F 0.01MF Z (TAPPING)
C901
CEXF1C470V
C ELECTRO
16V RSS 47MF (5X11) TP
C903
CEXF1C470V
C ELECTRO
16V RSS 47MF (5X11) TP
C905
CEXF1H101V
C ELECTRO
50V RSS 100MF (8X11.5) TP
C907
CMXM2A822J
C MYLAR
100V 8200PF J (TP)
C911
CCXB2H472K
C CERA
500V B 4700PF K (TAPPING)
C912
CCXB2H472K
C CERA
500V B 4700PF K (TAPPING)
C914
CXCH1H360J
C CERA
50V CH 36PF J (TAPPING)
C920
CEXF1H101V
C ELECTRO
50V RSS 100MF (8X11.5) TP
C922
CCXB2H561K
C CERA
500V B 560PF K (TAPPING)
C925
CEXF2E229V
C ELECTRO
250V RSS 2.2MF (8X11.5)TP
C929
CMXM2A104J
C MYLAR
100V 0.1MF J (TP)
C930
CMXM2A104J
C MYLAR
100V 0.1MF J (TP)
C935
CMXM2A104J
C MYLAR
100V 0.1MF J (TP)
C936
CMXM2A104J
C MYLAR
100V 0.1MF J (TP)
C937
CCXB2H561K
C CERA
500V B 560PF K (TAPPING)
C938
CMXM2A104J
C MYLAR
100V 0.1MF J (TP)
