34
LOC PART-CODE PART-NAME PART-DESC LOC PART-CODE PART-NAME PART-DESC
Service Parts List
R606 RD-2Z470J- R CARBON FILM 1/2 47 OHM J
R608 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R609 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R610 RD-AZ113J- R CARBON FILM 1/6 11K OHM J
R617 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R618 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R619 RD-AZ393J- R CARBON FILM 1/6 39K OHM J
R620 RD-AZ393J- R CARBON FILM 1/6 39K OHM J
R623 RD-4Z220J- R CARBON FILM 1/4 22 OHM J
R624 RD-4Z220J- R CARBON FILM 1/4 22 OHM J
R627 RD-2Z104J- R CARBON FILM 1/2 100K OHM J
R628 RD-2Z104J- R CARBON FILM 1/2 100K OHM J
R629 RD-2Z104J- R CARBON FILM 1/2 100K OHM J
R630 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R631 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R632 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R633 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R635 RD-2Z104J- R CARBON FILM 1/2 100K OHM J
R636 RD-2Z104J- R CARBON FILM 1/2 100K OHM J
R637 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R638 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R654 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R673 RD-4Z301J- R CARBON FILM 1/4 300 OHM J
R674 RD-4Z301J- R CARBON FILM 1/4 300 OHM J
R701 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R702 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R703 RD-AZ334J- R CARBON FILM 1/6 330K OHM J
R704 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R705 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R706 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R707 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R708 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R709 RD-AZ362J- R CARBON FILM 1/6 3.6K OHM J
R713 RD-AZ622J- R CARBON FILM 1/6 6.2K OHM J
R714 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R715 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R716 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R717 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R718 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R719 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R720 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R721 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R722 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R723 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R842 RD-AZ132J- R CARBON FILM 1/6 1.3K OHM J
R851 RD-4Z689J- R CARBON FILM 1/4 6.8 OHM J
R853 RD-4Z471J- R CARBON FILM 1/4 470 OHM J
R854 RD-4Z133J- R CARBON FILM 1/4 13K OHM J
R855 RD-4Z202J- R CARBON FILM 1/4 2K OHM J
R856 RC-2Z565KP R CARBON COMP 1/2 5.6M OHM K
Z101 5PMKT40MA- FILTER CERA MKT40MA100P
Z102 5PYXT5R5MB FILTER CERA XT 5.5MB
ZZ300 PEPWMSD018 PCB POWER MANUAL AS DSC-3270E
CF410 CMYH3D752J C MYLAR 2KV BUP 7500PF J
C402 CCXB3D151K C CERA 2KV B 150PF K (TAPPING)
C404 CMYH3D472J C MYLAR 2KV BUP 4700PF J
C405 CMYE2J153J C MYLAR 630V PU 0.015MF J
C406 CMYH3D522J C MYLAR 2KV BUP 5200PF J
C409 CEYD1H689V C ELECTRO 50V RUB 6.8MF (16*35.5)
C410 CMYE2G274J C MYLAR 400V PU 0.27MF J
C415 CEXF2E101V C ELECTRO 250V RSS 100MF 16X31.5
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C802 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C803 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C813 CEXF2G220C C ELECTRO 400V RUS 22MF (16X25) TP
C814 CEXN2W471P C ELECTRO 450V LHS 470MF (35X50)
C815 CMXH3C152J C MYLAR 1.6KV BUP 1500PF J (TP)
C831 CEYF2D221V C ELECTRO 200V RSS 220MF (18X40)
C835 CMXE2J154J C MYLAR 630V PFU 0.15MF J
C843 CH1FFF472M C CERA AC AC400V 4700PF F DE7150F
C870 CMXE2J472J C MYLAR PL 630V 4700PF J
D401 DFMLG12S— DIODE FML-G12S
D402 DFMRG5H— DIODE DAMPER FMRG5HS LF710
D402A 4857027607 HEAT SINK AL EX
D402B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
D403 DRU4AM—— DIODE RU 4-AM (TAPPING)
D801 DPBS208GU- DIODE BRIDGE PBS208GU-CA
D802 DPBS606GU- DIODE BRIDGE PBS606G
D802A 4857027702 HEAT SINK AL EX BK
D802B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
D815 DRGP30J— DIODE RGP30J
D816 DRGP30J— DIODE RGP30J
D817 DRGP30J— DIODE RGP30J
D818 DRU3YX—— DIODE RU3YX
D819 DRU3YX—— DIODE RU3YX
D820 DRGP30J— DIODE RGP30J
D821 DRGP30J— DIODE RGP30J
D823 DRGP30J— DIODE RGP30J
D825 DRL2AV1— DIODE RL2AV1
D831 DRL2AV1— DIODE RL2AV1
FBT1 5DH0000023 FBT FFA65039L
F801 5F3GB6322L FUSE GLASS TUBE V/S TL 6.3A 250V MF51
IF401 1KA4558— IC AMP KA4558
I301 1TDA8172— IC V-OUT TDA8172
I301A 4857028207 HEAT SINK AL EX BK
I301B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I801 1TNY253— IC POWER SW TNY253P
I802 1LTV817C— IC PHOTO COUPLER LTV-817C
I803 1STRS6709- IC POWER STR-S6709
I803A 4857027904 HEAT SINK AL EX (AN0DIZE)
I803B 7174301211 SCREW TAPPTITE TT2 RND 3X12 MFZN
I804 1LTV817C— IC PHOTO COUPLER LTV-817C
I808 1KA7805— IC REGULATOR KA7805
I808A 4857026902 HEAT SINK AL EX BK
