37
Service Parts List
LOC PART-CODE PART-NAME PART-DESC LOC PART-CODE PART-NAME PART-DESC
C401 CCXB3A471K C CERA 1KV B 470PF K (T)
C408 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C413 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C419 CCXB2H101K C CERA 500V B 100PF K (TAPPING)
C420 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C450 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C451 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C804 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C805 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C807 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C808 CXCH2H470J C CERA 500V CH 47PF J (TAPPING)
C816 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C817 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C819 CMXB2A102J C MYLAR 100V EU 1000PF J (TP)
C820 CCXF1H104Z C CERA 50V F 0.1MF Z
C821 CCXF1H104Z C CERA 50V F 0.1MF Z
C822 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C823 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C827 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C842 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C845 CMXE2A103J C MYLAR 100V PU 0.01MF J
C846 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C847 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C849 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C890 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C891 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C892 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C899 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
L402 58C0000096 COIL CHOKE 610G0233(470K)
L805 58C0000096 COIL CHOKE 610G0233(470K)
QF401 TKTA1266Y- TR KTA1266Y (TP)
QF402 TKTC3198Y- TR KTC3198Y
QF404 TKTA1266Y- TR KTA1266Y (TP)
Q401 TKTC3198Y- TR KTC3198Y
Q405 TKTC3198Y- TR KTC3198Y
Q406 TKTC3198Y- TR KTC3198Y
Q407 TKSA1013Y- TR KSA1013Y (TP)
Q430 TKSC2383Y- TR KSC2383-Y
Q802 TKSC2383Y- TR KSC2383-Y
Q803 TKSC2383Y- TR KSC2383-Y
Q804 T2SA1544— TR 2SA1544
R451 RV5426103P R SEMI FIXED ENV-DJAA03B14 10K OHM B
ZZ200 PEPWJAD018 PCB POWER AXIAL AS DSC-3270E
A001 4959805624 PCB POWER 330 X 246
DF401 D1N4937G— DIODE 1N4937G (TAPPING)
DF402 D1N4937G— DIODE 1N4937G (TAPPING)
DF403 D1N4937G— DIODE 1N4937G (TAPPING)
DF404 D1N4937G— DIODE 1N4937G (TAPPING)
D301 D1N4937G— DIODE 1N4937G (TAPPING)
D302 DUZ5R1BM— DIODE ZENER UZ-5.1BM
D404 DUZ5R6BM— DIODE ZENER UZ-5.6BM(TAPPING)
D406 DRF1——— DIODE RF1
D407 DRF1——— DIODE RF1
D409 D1N4937G— DIODE 1N4937G (TAPPING)
D410 DUZ12BM— DIODE ZENER UZ-12BM (UNIZON)
D411 DRF1——— DIODE RF1
D430 DUZ4R3B— DIODE ZENER UZ-4R3B
D431 DUZ12BM— DIODE ZENER UZ-12BM (UNIZON)
D803 DRL2AV1— DIODE RL2AV1
D804 D1N4937G— DIODE 1N4937G (TAPPING)
D805 DUZ7R5BM— DIODE ZENER UZ-7.5BM 7.5V
D806 D1N4937G— DIODE 1N4937G (TAPPING)
D807 D1N4937G— DIODE 1N4937G (TAPPING)
D808 DRF1——— DIODE RF1
D809 DUZ16BL— DIODE ZENER UZ16BL
D810 D1N4148— DIODE 1N4148 (TAPPING)
D811 D1N4148— DIODE 1N4148 (TAPPING)
D812 D1N4937G— DIODE 1N4937G (TAPPING)
D813 DUZ5R1BM— DIODE ZENER UZ-5.1BM
D814 DUZ33B—— DIODE ZENER UZ-33B
D822 D1N4148— DIODE 1N4148 (TAPPING)
D826 D1N4004S— DIODE 1N4004S
D827 D1N4937G— DIODE 1N4937G (TAPPING)
D828 D1N4937G— DIODE 1N4937G (TAPPING)
D857 D1N4148— DIODE 1N4148 (TAPPING)
J001 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J002 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J003 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J004 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J005 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J007 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J009 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J010 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J011 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J012 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J014 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J015 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J016 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J017 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J018 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J019 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J020 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J021 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J022 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J023 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J024 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J025 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J026 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J027 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J028 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
