ZTH200 Operating Instructions (Version 1.26)
P/D 102406
HomePro
by ADVANCED CONTROL TECHNOLOGIES, INC.
5
SYSTEM DESCRIPTION
The HomePro product line from Advanced Control Technologies includes several products that are intended to work together to
provide convenient control of all of your home lighting and appliances. By using the ZTH200 Wireless Controller, all of these
HomePro devices are linked by a state of the art wireless communications network featuring patented Z-Wave technology. This
technology insures that the commands that you give through the Wireless Controller are reliably communicated by radio frequency
to the intended HomePro device.
The Wireless Controller operates up to 64 HomePro devices, which include both plug-in and wall mounted dimmers and switches.
The Wireless Controller finds a way to route your commands to the intended device through other HomePro dimmers and switches.
This is possible because each of these devices are designed to retransmit the commands that are sent through them to adjacent
devices that might otherwise be out of range of the Wireless Controller. The Z-Wave system provides that a command can be
routed if necessary through as many as four different devices in route to the intended device.
Communication with devices employing Z-Wave technology is bidirectional. That is, when a command is sent from a Wireless
Controller, an acknowledgment is sent back to it by the affected devices to confirm that the command was received (not necessarily
that the load changed state). In the unusual situation in which a command is not properly received, a message will appear on the
Wireless Controller’s display to inform the User.
Introduction to HomePro Products
This controller is designed to work with the HomePro products shown. Most other Z-Wave modules of other device classes can be added to
the system and will also act as repeaters if they support this functionality..
ACT # Product Description
ZDP200 Dimmer, 300W, 230 VAC, Plug-in, Euro plug (Netherlands etc.), Ivory
ZRP200 Relay, 10A, Plug-in, 230 VAC, Euro plug (Netherlands etc.), Ivory
ZDP210 Dimmer, 300W, 230 VAC, Plug-in, UK plug, Ivory
ZRP210 Relay, 10A, Plug-in, 230 VAC, UK plug, Ivory
ZDP230 Dimmer, 300W, 230 VAC, Plug-in, French plug, Ivory
ZRP230 Relay, 10A, Plug-in, 230 VAC, French plug, Ivory
ZCS010 Transceiver-Controller, RS232 Interface - Euro Frequency (power supply not provided)
ZCU010 Transceiver-Controller, USB Interface - Euro Frequency, hub powered
ZCU011 Transceiver-Controller, USB Interface - Euro Frequency (power supply not provided)
ZTT000 Thermostat, 24V, Wall mount, Euro Frequency, White
ZIR010 Transmitter, PIR, Wall mount, Battery Operated, Euro Frequency, White
ZTH200 Transceiver, Wireless Controller
ZDP200
Plug-in Dimmer ZDP210
Plug-in Dimmer ZDP230
Plug-in Dimmer
ZIR000
PIR Occupancy &
Security Sensor
