ZDW120 Instructions, Release 1.1
P/D 102406 HomePro
by ADVANCED CONTROL TECHNOLOGIES, INC.
0671-01
2
Wire this Wall Mounted Dimmer in place of an existing wall switch according to the diagram. See the ZTH100
Wireless Controller operating instructions to add this module under the command of the Wireless Controller.
Air Gap Switch
The ZDW120 has an air gap switch on the face (lower left), that when pulled out, completely removes the power
available to the load (more so than simply turning the dimmer off). This enables the lamps that are controlled by
the device to be changed with minimal danger of electrical shock. The air gap switch must be pushed all the way
back in for the dimmer to operate the lamps again.
BASIC OPERATION
Local Control
The ZDW120 allows the user to
• Turn ON or OFF, DIM or BRIGHTEN, the load attached.
• Include or exclude the module from the Z-Wave system
• Control other Z-Wave enabled devices.
Also, when a controller prompts you to “Send Node ID” or to “Press Button on Unit”, quickly tap on the top or bottom
of the paddle once to satisfy those instructions.
• Tapping top of the paddle turns the load attached ON.
• Tapping bottom of the paddle turns the load attached OFF.
• Pressing and holding the top of the paddle will brighten the load attached, and pressing and holding the bottom
of the paddle will dim the load. When OFF, pressing and holding the bottom of the paddle will cause the load
will go to the minimum dim level.
Note: Upon restoration of power after a power loss, the ZDW120 defaults OFF.
LED indication
The LED on the ZDW120 will turn on when the load attached is ON. However, the LED can be user configured
to turn ON when the load attached is OFF, if so desired, to act as a night light.
The ZDW120 will flicker its LED when it is transmitting to any of its 4 groups. This can be changed if desired.
ADVANCED OPERATION
All On/All Off
The ZDW120 supports the ALL ON/ ALL OFF commands.
The ZDW120 can be set to respond to ALL ON and ALL OFF commands 4 different ways.
Refer to your controller for information on how to set the ZDW120 to operate in the manner you desire. Some
controllers may be only able to set certain settings of ALL ON/ALL OFF response.
The 4 different ways the ZDW120 can be setup to respond to ALL ON and ALL OFF commands are:
• ZDW120 will not respond to ALL ON or the ALL OFF command.
• ZDW120 will respond to ALL OFF command but will not respond to ALL ON command.
• ZDW120 will respond to ALL ON command but will not respond to ALL OFF command.
• ZDW120 will respond to ALL ON and the ALL OFF command (default).
Association
The ZDW120 supports the Association command.
The ZDW120 can be set to control other Z-Wave devices. Those devices must be installed in their permanent
location. You can turn on and off, and even dim other Z-Wave devices once they are “associated” into 1 of 4 groups
within the ZDW120.
Each group is turned on or off (or dimmed) by tapping or holding the paddle a differing amount of times.
If you associate a Z-Wave device into Group 1, you can turn that device on and off by tapping the paddle on or
off once. The load attached to the ZDW120 will also turn on or off. Associating nodes into group 2 or 3 will cause
a very slight delay before the command is transmitted to group 1 nodes.
