Dimmable controlLED Lite
• ControlLED Lites fit standard fluorescent fixtures and their tombstone connectors..
• LED Driver and Signal Conditioner fits standard fluorescent ballast footprint.
• Reduced power consumption per fixture - (total - 4 each 4 foot tubes). Only 66W LED + 6W for
Driver vs. 160W Fluorescent + 18 for ballast.
• Cost effective dimming...saves additional dollars every time you do it.
• One LED Driver will power up to four controlLED Lites. If multiple light fixtures are to be
controlled within an area, only the first light fixture needs a Signal Conditioner (one Signal
Conditioner will control up to 12 LED Drivers via a twisted pair of wires).
• Dimmable ControlLED Lites are available in Warm White, White and Cool White.
• Shatter Resistant.
• No mercury.
Line Voltage
Dimming
Control Signal
LED Tube
LED
Controller
Typical
Wiring
3
