once or wait for 60 seconds at which point the RB304 will return to the RUN mode.
ON/OFF/AUTO CONTROL SWITCH:
1. In the ON position the relay is energized at all times. The green RELAY status LED indicates
when the relay is energized.
2. In the OFF position the relay will never energize.
3. In the AUTO position the relay will be controlled by the PCC signal and the Remote Manual
Override Switch.
CHECKOUT
1. Test Operation:
Using a controller, transmit appropriate commands to ensure proper operation and
interference filtering. This product is compatible with standard X-10 systems.
2. If at any time the STATUS LED flashes off and on quickly without stopping, reset the RB304
by powering the unit down and back up. If the error returns and cannot be cleared through
a reset, the unit could need repair or replacement.
Supply Voltage 277 VAC, +/-10%, or 480 VAC, +5/-10%, 50 or 60 Hz
Power Consumption Less than 4.5W
Powerline Carrier Signal Input X-10 Powerline Carrier, sensitive to 50 millivolts
Signal Output (Status) X-10 Powerline Carrier, 6V peak to peak @ 5 ohms
Maximum switching capacity Resistive: 30A, 300 VAC or 15A, 600 VAC - N.C. or N.O. contacts
Motor: 1 H.P., 120 VAC or 1.5 H.P. 200 to 600 VAC - N.C. or N.O. contacts
Restive DC: 30A, 28 VDC, - N.C. or N. O. contacts
Fuses Two (2) 13 x 32mm fast acting fuses rated 0.5A, 600V (control circuit)
