ADVANCED CONTROL TECHNOLOGIES, INC.
Indianapolis, Indiana 46278 RB204 Installation Instructions
P/D 062403
Supply Voltage 240 VAC, +/-10%, 50 or 60 Hz
Power Consumption Less than 4.5W
Powerline Carrier Signal Input X10 Powerline Carrier, sensitive to 50 millivolts
Signal Output (Status)
X10 Powerline Carrier, 6V peak to peak @ 5 ohms
Maximum switching capacity Resistive: 30A, 277 VAC - N.C. or N.O. contacts
Motor: 1 H.P., 120 VAC or 1.5 H.P. 200 -600 VAC - N.C. or N.O. contacts
Ballast: 120 VAC, 10A - N.C. contact or 30A - N.O. /277 VAC, 10A - N.C. contact or 20A - N.O.
Tungsten 2A, 120 VAC - N.C. contact or 10A, 120 VAC - N.O. contact
Resistive DC: 30A, 28 VDC, - N.C. or N. O. contacts
Fuse One (1) 13 x 32mm fast acting fuse rated 0.5A, 600V (control circuit)
d) The user may exit the PROGRAM 2 mode by pressing the PROGRAM push button
once or wait for 60 seconds at which point the RB204 will return to the RUN mode.
ON/OFF/AUTO CONTROL SWITCH:
1. In the ON position the relay is energized at all times. The green RELAY status LED indicates
when the relay is energized.
2. In the OFF position the relay will never energize.
3. In the AUTO position the relay will be controlled by the PCC signal and the Remote Manual
Override Switch.
CHECKOUT
1. Test Operation:
Using a controller, transmit appropriate commands to ensure proper operation and
interference filtering. This product is compatible with standard X10 systems.
2. If at any time the STATUS LED flashes off and on quickly without stopping, reset the RB204
by powering the unit down and back up. If the error returns and cannot be cleared through
a reset, the unit could need repair or replacement.
