CR334 Installation Instructions
P/D 011904
opposite is possible; the Ignore SCC Repeated Signal can be disabled while the Ignore Repeated
Signal option is enabled, allowing SCC repeated code to be repeated while not allowing repeated
signals on the power phases to be repeated.
Three Phase/Split Phase Operation
The CR334 can operate in a Three Phase System or two phases of 277 VAC.
X10 Extended Code 1
The CR334 can accept X10 Extended Code 1.
Handles Preset Dim Commands
Repeat on ALL Active Phases/Repeat on SCC line only
The CR334 can be configured to repeat on all active phases including SCC or it can be configured
to repeat on SCC only. When the CR334 is configured to repeat on SCC only, the TRANSMIT led
will flicker when repeating.
Repeat at 0
°
and 30
°
/Repeat at
°
0 only
The CR334 can be configured to repeat at 0
°
and 30
°
or it can be configured to repeat at only 0
°
.
Smart SCC
Smart SCC is an option that is always enabled. When the CR334 receives signal on the SCC line
and repeats it, the signal will not be repeated back onto the SCC line. When the CR334 is
repeating signal received from the SCC line, the RECEIVE led will flicker.
WARRANTY
For warranty and general product information visit our web site at
www.act-solutions.com
ABOUT CR334 CERTIFICATION
The CR334 has been thoroughly tested by the ETL SEMKO division of
Intertek, a nationally recognized testing laboratory. This product was
found to be in compliance with safety standards ANSI/UL STD 244A
and CAN/CSA C22.2 No. 177. RECOGNIZED COMPONENT
Power
Supply Voltage 277 VAC, +/-10%, 50/60 Hz
Fuses (field replaceable) Phase A (Power): 800mA, 277V (Belfuse MRT series)
Phase B & C: 500mA, 277V (Belfuse MRT series)
Signal
Signal Input X10 Powerline Carrier on any phase (sensitive to 25 millivolts peak to
peak), (SCC) Signal Carrying Conductor (sensitive to 50 millivolts
peak to peak)
Signal Output X10 Powerline Carrier (including SCC), 5V peak to peak @ 5 ohms
Connection 12" (30.4 cm) flying leads of 16 ga. insulated wire
SCC
Connections Plug-in terminal block
Wire Size 12 to 22 AWG
Wire Strip Length 5/16" (3.81 mm)
