3 Function Diagram
CPU
Intel® Atom™
N2600
N2800
D2550
Analog VGA
DDR3
Memory
Controller
DP/HDMI
Graphics Core
640 MHz
SODIMM
DDR3 1066 MHz
LAN PHY
Realtek
RTL8111E
SA
TA
Intel ® NM10
Chipset
BIOS
Debug
Header
X2
X1
X4
X3
LPC
PCIe x1
USB 2.0
PCI
Controller
Audio
Keyboard
LPT1/FDD
COM2
I 2 C
PCIe x1
Super I/O
Winbond
W83627DHG
RTC Audio Codec
Realtek
ALC262
PATA
IDE0/IDE1
PCI Bus
PCI / ISA
IT8888G
SATA
SA
TA
PCIe x1
VGA
4 ports USB 2.0 SPI
2.5 GT/s DMI
SMBus
COM1
Mouse
PCIe-to-PATA
Marvell
88SE6101
DP to LVDS
Chrontel
CH7511
BC
PCIe-to-PATA
Marvell
88SE6101
