2 Specifications
2.1 Core System
¾ CPU: 4th Generation Intel® Core™ processor SoC (formerly "Haswell-ULT", Ultra Low TDP)
• Intel® Core™ i7-4650U 1.7 GHz (3.3 GHz Turbo), 15W (2C/GT3)
• Intel® Core™ i5-4300U 1.9 GHz (2.9 GHz Turbo), 15W (2C/GT2)
• Intel® Core™ i3-4010U 1.7 GHz (no Turbo) 3MB, 15W (2C/GT2)
• Intel® Celeron® 2980U 1.6 GHz (no Turbo), 15W (2C/HDG)
Supporting: Intel® VT, Intel® TXT, Intel® SSE4.2, Intel® HT Technology, Intel® 64 Architecture, Execute Disable Bit,
Intel® Turbo Boost Technology 2.0, Intel® AVX2, Intel® AES-NI, PCLMULQDQ Instruction, Intel® Secure Key and Intel® TSX
¾ L3 Cache: 4MB for Core™ i7-4650U, 3MB for Core™ i5-4300U and Core™ i3-4010U, 2MB for Celeron® 2980U
¾ Memory: Dual channel non-ECC 1600/1333 MHz DDR3L memory up to 16 GB in dual SODIMM socket
¾ BIOS: AMI EFI with CMOS backup in 8MB SPI BIOS with Intel® AMT 9.0 support
2.2 Expansion Busses
¾ 4 PCI Express x1 (AB): Lanes 0/1/2/3
¾ LPC bus, SMBus (system) , I 2 C (user)
2.3 Video
¾ Integrated in Processor: Intel® Generation 7.5 graphics core architecture
¾ GPU Feature Support:
• 3 independent and simultaneous display combinations of DisplayPort / HDMI / LVDS monitors
• Encode/transcode HD content
• Playback of high definition content including Blu-ray Disc
• Superior image quality with sharper, more colorful images
• Playback of Blu-ray disc S3D content using HDMI (1.4a spec compliant with 3D)
• DirectX Video Acceleration (DXVA) support for accelerating video processing
• Full AVC/VC1/MPEG2 HW decode
• Advanced Scheduler 2.0, 1.0, XPDM support
• Windows 8, Windows 7, OSX, Linux OS support
• DirectX 11
• Multi Display Support: 3 independent displays
¾ Display Types
• LVDS interface single/dual channel 18/24-bit LVDS through eDP (two lane) to LVDS Realtek RTD2136R
• Digital Display Ports x2
DDI1 supports DisplayPort / HDMI / DVI
DDI2 supports DisplayPort / HDMI / DVI
