Specifications
Serial Ports
Four16C550 serial ports
• One DB-9 RS-232/422/485 serial port on front panel
• Three serial ports routed to rear I/O through J3 (1x RS-
232/422/485, 2x TX/RX only)
PCI Express
• PCIe x16 Gen2 to J4
• PCIe x4 Gen2 to J5
USB 2.0
• Six USB 2.0 ports routed to J3
USB 3.0
• Three USB 3.0 ports on front panel, one to J5
KB/MS
• PS/2 Keyboard/Mouse port to J3
Audio
• High Definition Audio signals routed to J3
TPM
Atmel AT97SC3204 TPM (upon request)
• Over/Under voltage detection
• Low/High frequency sensor/filter
• Reset filter
• Memory Encryption/Decryption
Storage
Interfaces
1
• One SATA 6 Gb/s direct connector for 2.5" onboard drive
(removable)
1
• One SATA 6 Gb/s CFast slot by adapter board
• Three SATA 3Gb/s to rear IO
Faceplate I/O
• 2x 10/100/1000BASE-T Ethernet ports
• 1x DVI-I (RGB switchable to rear)
• 3x USB 3.0 ports
• 1x RJ-45 RS-232/422/485 port
OS
Compatibility
• Microsoft Windows 7 32/64-bit
• Red Hat Enterprise Linux 6.2 x86 64-bit
• Fedora 16 x86 64-bit
• Wind River VxWorks 6.9 BSP
• Other OS support on request
Environmental
• Operating Temperature
2
:
Standard: 0 to 60°C with forced air flow
ETT: -20°C to 70°C with forced air flow (cPCI-ET6520)
EX: -40°C to 85°C with forced air flow (Core™ i7-3555LE &
Core™ i7-3517UE only)
• Storage Temperature: -40°C to 85°C
• Humidity: 95% non-condensing
• Shock: 15G peak-to-peak, 11ms duration, non-operating
• Vibration
3
: Operating 2 Grms, 5-500Hz, each axis w/o hard
drive
EMI
• CE EN55022
• FCC Class A
Table 2-1: cPCI-6525 Blade Specifications
