Revision: 1.0
21
SATA 2 x SATA II port,
CF 1 x External Compact Flash Type I/II socket
Disk Bay 1 x Anti-shock 2.5" HDD bracket swappable without open case
I/O
Ethernet 2 x Gbps RJ45 with LED, Broadcom BCM5787
Serial Port 4 x RS-232
(2 x DB9, 2 x pin header, COM3 for reserve for PIC on power circuit,
COM4 for GPS
USB 7 x USB2.0
(4 x external port, 3 x pin header)
GPIO 4-bit GPIO (2 In, 2 Out) with 5 pin terminal block, 2-in/GND/2-out
Audio IC: Realtek ALC655
Interface : MIC-In, SPK-Out
Remote control 1 x Remote control
Fuse 7.5A
Antenna Hole 1 x SMA for GPS, 1 x SMA for 3.5G, 1 x SMA for WiFi+Bluetooth
miniPCIe 1 x miniPCIe option for MC8790
SIM SIM slot x1, SIM card changeable without opening case, latch to protect
SIM uncertainly touch
Expansion
PCI-104 Keep design, remove PCI-104 slot
Others
GPS(option) Globalsat ER-332
3.5G(option) Sierra MC 8790/8790V, through miniPCIe slot on AR-B5403
WiFi(option) (1)2 in 1 module (WLBT-Combo-E), (2)
Bluetooth 2 in 1 module (WLBT-Combo-E)
Software
OS support Windows XP/ XP embedded, Linux FC 6 /7
Power Power onboard design(AR-B5403)
z Wide range input DC 9V~32V
z Fuse
Design
z Smart ATX power function:
a. Power on/off retry
b. Adjustable delay time for system OFF by Switch on power module
(Mode2~Mode7)
c. System on/off by Vehicle ignition or Remote switch button
d. Low Power input monitoring, Auto shutdown
z S/W configurable by COM3
