AR-B7290
18
Internal Connector
Label Function Note Page
AAFP Front Panel Audio Connector 5 x 2 header, pitch 2.54mm 37
ATX12V ATX Power Connector 2 x 2 header 38
ATXPWR ATX Power Connector 10 x 2 header 38
CHA_FAN Chassis Fan Connector 3 x 1 wafer, pitch 2.54mm 39
CPU_FAN CPU Fan Connector 4 x 1 wafer, pitch 2.54mm 39
F_PANEL System Panel Connector 5 x 2 header, pitch 2.54mm 40
JAMP1 Amplifier Connector 4 x 1 header, pitch 2.54mm 41
JBKL LCD Inverter Connector 5 x 1 header, pitch 2.00mm 41
JDIO Digital I/O Connector 5 x 2 header, pitch 2.00mm 42
JLVDS LVDS Connector HIROSE DF13S-40DP-1.25V 42
JSPI JSPI Connector 4 x 2 header, pitch 2.54mm 42
PRI_IDE Primary IDE Connector 20 x 2 header, pitch 2.54mm 43
SATA1, SATA Serial ATA Connectors 1~2
[red] 7-pin header 44
USB56 USB 2.0 Connector 5 x 2 header, pitch 2.54mm 45
