AR-B7290 17
1.3.1
Layout Content List
Slots
Label Function Note Page
CF Compact Flash socket (Rear Side) N/A
MINI_PCIE Mini PCI-E slot N/A
PCI1 PCI slot N/A
SODIMM_A1 200-pin SODIMM slot 1 N/A
SODIMM_B1 200-pin SODIMM slot 2 N/A
Jumpers
Label Function Note Page
CLRTC Clear CMOS 3 x 1 header, pitch 2.54mm 32
JCOMPWR1 COM1 RI/+5V/+12V Selection 3 x 2 header, pitch 2.54mm 33
JCOMPWR2 COM2 RI/+5V/+12V Selection 3 x 2 header, pitch 2.54mm 33
Rear Panel Connector
Label Function Note Page
KBMS PS/2 keyboard and mouse 6-pin Mini-Din 34,36
COM12 Serial Port Connector D-sub 9-pin, male 34,36
VGA_DVI VGA Connector D-sub 15-pin, female 34,36
USB34 USB Connector x 2 36
LAN1_USB12 RJ-45 Ethernet Connector x 1
USB Connector x 2
34,35
AUDIO Line-in Port, Line-out Port,
Microphone Port, 5.1 Channel Audio I/O (3 jacks) 34,35
