AR-B7230 User’s Manual
8
z LCD :
1 x Dual Channel 18bits LVDS Interface
LCD inverter power connector and ON/OFF control
Support 3.3V and 5V LCD
AUDIO
z Audio Interface : 5.1 CH Audio Realtek ALC655 AC’97 Rev.2.3 with amp.
Storage
z IDE : 1 x E-IDE
z SSD :
1 x Compactflash Type-II support UDMA
1 x SATA DOM connector
z FDC : N/A
z SATA : 1 x SATA HDD and one SATA DOM interface
Network Interface
z Ethernet : 2 x BCM5787 PCI express Giga bps Ethernet LAN Support boot from
LAN & WOL
I/O
z Serial Port :
1 x RS-232 (COM1)
2 x RS-232 (COM2/3)
1 x RS-232/422/485 (COM4)
z Parallel Port : 1 x LPT supports SPP/EPP/ECP modes
z GPIO : 8 Independent TTL level I/O
z USB : 2 x External ports (Stacked Type A)
z Audio : 5.1 CH Audio
z Expansion slot : 1 x PCI-104 (PCI Interface)
z Keyboard / Mouse : 1 x PS/2 for Keyboard and Mouse
Mechanical
z Dimension :
115mm x 165mm (4.528 x 6.496 inches)
z Operating Temperature : 0~60
o
C (32~140
o
F)
z Storage Temperature : -20~80
o
C (-4~176
o
F)
z Relative Humidity : 0 to 90% @ 40°C, non-condensing (95% @ 40°C,
Non-Condensing by request)
EMC & Safety
z EMC : CE, FCC Class A
Notes:
CF must be surfaced with PCB edge.
Dual Display CRT+LCD, DVI+LCD, CRT+DVI
