background image

AR-B1651 User’s Guide

11

! USB1

USB1 use an adapter cable to interface with external equipment.

1 9

2 10

1.VCC

2.VCC

3.DATA3-

4.DATA4-

5.DATA3+

6.DATA4+

7.8.GND

9.10.GND

2.2.8 LVDS Header (LVDS1)

1 13

14 26

















2.2.9 VOLTAGE SELECT (JP2)

■ LVDS

1

3

5

2

4

6

JP2

JUMPER VOLTAGE

NOTE

1-3 ON
2-4 ON

VCC

3-5 ON
4-6 ON

VCC3

Factory preset

2.2.10 PANEL BACKLIGHT CONNECTOR(JP5)

1. +12V

2. GND

3. Enable Panel Backlight

JP5

JP5

JP5

JP5

PIN (LVDS1)

FUNCTION

PIN (LVDS1)

FUNCTION

1 TXOUT0-

14 GND

2 TXOUT0+

15 GND

3 TXOUT1-

16 VTX5

4 TXOUT1+

17 VTX5

5 TXOUT2-

18 NC

6 TXOUT2+

19 GND

7 TXCLK-

20 GND

8 TXCLK+

21

VTX12

9 TXOUT3-

22 VTX12

10 TXOUT3+

23 GND

11 VTKBP

24 NC

12 VTX5

25 NC

13 VTX5

26 NC
