Chapter 1 Introduction
ACM-B6360 is a COM Express Type 6 Basic module that fully complies with the PCI
Industrial Computer. It supports 3
rd
Generation Intel ® core TM i7 processors. It
integrates Intel ® PCH QM77 chipset. Besides basic I/O ports support like VGA, LVDS,
USB2.0, USB3.0, COM. LAN, and GPIO with ACM-B4080 (optional).
1.1 Specifications
ACM-B6360
CPU Intel Core i7 3615QE
Chipset Intel QM77 chipset
Memory SO-DIMM ECC DDR3, Max:16GB
RAID support 0, 1, 5, 0+1
OS support Linux Fedora 14, Windows XP, Windows 7, Ubuntu 10
Follow COM Express type 6
ACM-B4080(Optional)
Ethernet 1 x RJ45 10/100/1000Mbps LAN ports
Serial Port 2 x RS-232 (pin-header, RX/TX signal only)
USB 2.0 x 4(pin-header x2, I/O x2), USB3.0 x4(I/O)
Flexible GPIO ports (8 bits digital I/O (4 x IN & 4 x OUT)
SATA II x2(6.0Gb/s), SATA III x 2(3.0Gb/s)
Video VGA (DB15) & LVDS
Digital display Interface SDVO x1 & HDMI x2
Audio Line-in, Line-out & MIC phone jack
PCIe x16 slot x1, PCIe x4 slot x1, PCIe x1 slot x3
Mini-PCIe x1 (ACM-B6360 not supported)
SPI, SMBus, LPC, Port 80 display
ATX Form factor
