6.3.1 Cash Drawer Communications
ITEM
SPECIFICATION
Communication type
Cash Drawer kick-out interface
Emulation
Epson 24V (TM-T85, TM-T88) compatible
Connector Type
RJ12
Pin Assignments
Pin#
Signal
1
Frame Ground
2
Drawer kick-out signal 1
3
VCC = +24V
4
VCC = +24V
5
Drawer kick-out signal 2
6
Frame Ground
6.4 Electrical Characteristics
ITEM
SPECIFICATION
Printer supply voltage
16 VAC @ 2.2 A
Power consumption
<50 W printing mode
<1 W idle mode (automatic)
AC/DC adapter
In 16 VAC @ 2.2A
230Vac / 50Hz (CE plug)
230Vac / 50Hz (GB plug)
120Vac / 60Hz (US plug)
6.5 Mechanical
ITEM
SPECIFICATION
Material housing
Plastic
Weight of printer
Weight of AC/DC adapter
1.43 lbs. (650 g)
1.98 lbs. (900 g)
