6.1 Media
See Section 2.2 for more information.
ITEM SPECIFICATION
Media type Direct thermal paper
Maximum media width 3.35” (85mm)
Roll dimensions 2.36” (60mm) maximum diameter
6.2 User Interface
ITEM SPECIFICATION
Power supply connector
(rear) Jack type male socket
Communication connector
(rear) Mini-DIN socket
Red LED (upper side) « ON / OFF » and error
Green LED (upper side) « ON/OFF LINE » , Menu, idle mode
Left hand push button (upper
side) « ON/OFF », « ON LINE », « YES » functions
Right hand push button
(upper side) Line and form feed « LF/FF » and « NO »
function
Parameter settings (printout
menu) Push button entry (with a simultaneous push on
both buttons)
6.3 Communications
ITEM SPECIFICATION
Communication type RS232C
Parameter settings
(configuration mode) Printout menu
Baud rate 1200 to 115200 baud (step by step)
Data format 7 or 8 bits data bits
With or w/o parity bit (odd or even)
1 Start bit 1 Stop (free)
Data exchange control Xon / Xoff or DTR/RTS
(active at 0 or 1 level)
