1-3
x Introduction to the Projector
This chapter introduces you to the 9060 high end
fixed installation projector and describes key features and con-
trols.
Congratulations on Your Purchase of the
projector
The 9060 is a sophisticated three panel, dual
lamp XGA LCD projector. With the 9060 you will be
able to project images up to 500" (measured diagonally) from
your DVD player, VCR, satellite hookup, HDTV source, PC, Work-
station or Macintosh computer (desktop or notebook) and im-
ages from you digital camera PC Card or compact flash memory.
The
Dukane 9060 incorporates integrated networking access
through the RJ45 input or provides for wireless network connec-
tivity from an optional wireless network PC card. With extensive
input and output panels, optional long life lamp, full suite of quick-
change lenses and a full function remote, the
9060
will let you immerse yourself in large screen viewing.
Features you’ll enjoy on the 9060 :
• Integrated RJ45 connector for wired networking ability
• Two optional modular card slots allow for future projector growth
with the ability to add additional input cards
• Dual PC card slots provide for optional wireless/wired network
connectivity or PC Card usage
• Email projector error status information to selected individuals
• Power Horizontal and Vertical lens shift for optical display cor-
rections
• Lens memory controls lens attributes (zoom, focus, shift) de-
pending on input resolution and input selected for fast and easy
source transitions
• D esigned and developed SweetVision TM
technology for
enhanced video image display, more vibrant colors and blacks
richer with detail
• 3D Reform enhanced image technology for increased projec-
tor versatility that provides for horizontal, vertical and diagonal
keystone correction (allows for positioning the projector in off
center locations in the room and still get aligned images)
• Display 16:9 or 4:3 information and fill the screen
• HDTV (1080p, 1080i, 720p) and SDTV (576p, 576i, 480p, 480i)
compatibility
• 9060 supports a native resolution of XGA (1024
ן768) and
• Intelligent lamp technology offers up to six user lamp settings
to maximize light output or lamp life and provide for built in
redundancy
• Smart security settings for password protection, control panel
lock, menu lock and PC card protection key to help prevent
unauthorized access and adjustments to the projector
• ADA508 and Executive Order 13221 Federal Government com-
pliance * 1
• NEC 3D 10-bit video decoder for expanded black levels and
adaptive gamma correction
• High performance optional long life lamp for low total operat-
ing costs
• Digital photo viewer to display larger than life images from your
digital cameras PC card or compact flash card
• Double stackable for built in redundancy and high light output
requirements
• Built in 5W ן2 speakers for an integrated audio solution
• Two timer settings - On/Off with programming or Sleep timer
that counts down at selected intervals
• 12V low voltage Screen Trigger output
• Easy set up and operation
• Eco-mode™ lamp technology for increased lamp life and en-
ergy savings
• VORTEX Technology Plus™ for uncompromising display of
video and data. Improves white level, color accuracy, dynamic
range, and display of varying levels of black in an image
• Wireless remote control operation
• External control via RS232, USB or Network
• Advanced AccuBlend intelligent pixel blend ing
technology provides for extremely accurate image com-
pression and HDTV (1920
ן1080) display resolution* 2 .
• Supports most IBM VGA, SVGA, XGA, Macintosh, component
signal (YCbCr/YPbPr) or other RGB signals within a horizon-
tal frequency range of 15 to 100 kHz and a vertical frequency
range of 48 to 120 Hz. This includes NTSC, NTSC4.43, PAL,
PAL-M, PAL-N, PAL60 and SECAM standard video signals
NOTE: Composite video standards are as follows:
NTSC: U.S. TV standard for video in U.S. and Canada.
NTSC4.43: TV standard used in Middle East countries.
PAL: TV standard used in Western Europe.
PAL-M: TV standard used in Brazil.
PAL-N: TV standard used in Argentine, Paraguay and Uruguay.
PAL60: TV standard used for NTSC playback on PAL TVs.
SECAM: TV standard used in France and Eastern Europe.
* 1 The 9060 meets ADA508 compliance, the latest American
government regulation which provides for closed captioning,
including a menu system that can be viewed by colorblind us-
ers. This model also meets Executive Order 13221 require-
ment for standby operation, which consumes less than 1 watt.
* 2 HDTV 1080P (1920 ן1080), HDTV 1080i (1920ן1080), HDTV
720 p (1280 ן720) and 1600ן1200 are displayed with
Advanced AccuBlend technology on the 9060 .
1. Introduction
