Q-See Q25DVR4ES User’s Manual
Page 14
After completing the “MOTION SETUP”, User can exit by clicking [ Menu],
and press [ Record] to start Motion Recording.
Chapter 5: DVR Setup - 5.14 Motion Setup
CHANNEL SENSITIVITY:
Press [ Select] to adjust sensitivity of
motion detection on each channel.
High (1----------9, OFF) Low
When it’s OFF, the channel cannot be
triggered by movement.
MOTION RECORD TIME:
This number indicates how long the
triggered recording lasts after the DVR
has been triggered by motion.
MOTION ALARM TIME:
This number indicates how long the
buzzer inside the DVR will sound when a
motion event has been detected.
MOTION SET:
User needs to have video record method
set to Motion Trigger. (Refer to 5.7
Schedule Set)
CHANNEL AREA SET:
Press “ Select” to enter the sensitive area of each camera. The picture of the selected channel is
divided into 144(12*12) blocks, press [REW] to move left, press [FWD] to move right, press [UP] to move
up, press [DOWN] to move down, press [ Select] to set the block to being active or not.
When the block is transparent, it’s active to record. When the block is covered by shadow, it is not
active, and motion in this area will NOT be recorded.
Make sure Record Schedule is set to Motion for the times required.
MOTION SET
MOTION RECORD TIME: 10
MOTION ALARM TIME: OFF
MOTION SET
PRESS (UP, DOWN), ENTER (SELECT)
PRESS (MENU) TO EXIT
MOTION SET
CHANNEL 1 SENSITIVITY 4
CHANNEL 2 SENSITIVITY 4
CHANNEL 3 SENSITIVITY 4
CHANNEL 4 SENSITIVITY 4
CHANNEL 1 AREA SET
CHANNEL 2 AREA SET
CHANNEL 3 AREA SET
CHANNEL 4 AREA SET
PRESS (UP, DOWN), ENTER (SELECT)
PRESS (MENU) TO EXIT
