62 Jackrabbit (BL1800)
A.2 Jumper Configurations
Figure A-4 shows the header and jumper locations used to configure the various Jackrabbit
options.
Figure A-4. Location of Jackrabbit Configurable Positions
R55
R56
D21
C27
D24
JP2
R16
R17
R18
JP1
Z-World, Inc. JACKRABBIT
JP3
Top Side
Bottom Side
CAUTION
Battery
