REMOTE CONTROL USAGE (FIGURE 11)
The fireplace is supplied with a radio frequency remote control. This remote control has a
range of approximately 25 feet. (17.5m), it does not have to be pointed at the fireplace and
can pass through most obstacles (including walls).
Remote Control Initialization
This procedure is required every time there is a loss of
power to the remote control in the fireplace. (i.e. power
failure, breaker tripped, main power switch is turned off)
1. Ensure that power is supplied through main
service panel.
2. Locate manual controls (refer to page 6).
3. Activate main power switch, red indicator light on
the main power switch will illuminate.
4. Press ON button located on the remote control
transmitter (FIGURE 1). This will synchronize
the remote control transmitter and receiver.
Remote Control Usage
The remote control operates the fireplace levels
sequentially. The level is increased every time the
ON button on the transmitter is pressed. The
fireplace can be turned off at any point by pressing the
OFF button on the remote control transmitter.
Level 1: The flame effect is turned on and the first red
indicator light illuminates.
Level 2: The flame effect remains on, the heater is
activated to the low heat setting, and the first and
second red indicator lights illuminate.
Level 3: The flame effect remains on, the heater is
set to the high heat setting, and all three red
indicators illuminate.
.
MANUAL SELECTION SWITCH
Operates fireplace in the same matter as the remote
control transmitter. Pressing the
-
button has the
same effect as the ON button on the remote control,
and the O button has the same effect as the OFF
button of the remote control. Pressing - once
activates Level 1, twice activates Level 2, three times
activates Level 3. Pressing
O button turns the fireplace
off.
Level 3 indicator
Level 2 indicator
Level 1 indicator
FIGURE 11
Manual selection buttons
