PARTS LIST
FIREPLACE MODELS
VTGF33NRB AND VTGF33PRB
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 31 of this manual.
KEY
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
101357-03
Top Outer Casing
1
2
101351-01CK Top Front
1
3
101353-01CK Middle Front Rail
1
4
111339-01
Blower Duct
1
5
**
Firebox Top
1
6
101712-03
Firebox Hood
1
7
102759-02CK Left Front Side
1
8
102758-02CK Right Front Side
1
9
M11084-26
Hex Screw, #10
60
10
099230-01
Shoulder Screw
4
11
**
Firebox Wrapper
1
12
101514-01
Cover
1
13
098304-01
Phillips Pan Head Screw, #10
22
14
**
Firebox Support
2
15
102455-18
Louver
2
16
104313-01
Hinge, Pin
1
17
104313-02
Hinge, Pin
1
18
M10908-2
Screw, Slotted Hex Head Tapping
4
19
098304-02
Phillips Pan Head Screw, 6-20 x .38
4
20
101346-01
Outer Base
1
21
101727-03
Screen Assembly
1
22 **
Outer Casing
1
23
111547-01
Blower
1
PARTS AVAILABLE — NOT SHOWN
100639-01
Caution Decal
1
104356-02
Warning Decal
1
** Not a field replacement part.
