www.desatech.com 113134-01E 33
KEY PART
NO. NUMBER
DESCRIPTION QTY.
1 110103-01 Ember Bed Log 1
2 110105-02 Left Front Log 1
3 110105-01 Right Front Log 1
4 110105-03 Rear Log 1
5 110105-04 Right Crossover Log 1
6 110104-01 Left Crossover Log 1
7 103904-02 Electrode 1
8 104285-02 ODS Pilot (Natural) 1
104286-02 ODS Pilot (Propane/LP) 1
9 110093-05 Electrode Bracket 1
10 099387-09 Pilot Tube 1
11 111323-01 Pilot Shield 1
12 108105-02 Rear Burner 1
13 102843-01 Burner Clip 1
14 107110-01 Spacer 2
15 100321-01 Spacer 2
16 107566-01 Module, Control Board 1
17 102349-01 Support, PCB 4
18 107565-01 Receiver Assembly 1
19 107565-02 Sensor Assembly 1
20 098303-02 Screw, #6 2
21 M11084-50 Screws 4
22 108631-01 Log Alignment Screw 9
23 ** Firebox Bottom 1
24 107563-01 Wall Switch and Cord 1
25 107558-01 Wall Switch
Decorative Plate 1
26 107561-01 Wall Plate Decal 1
27 100694-01 Screw, #6 x 1 1 /
4
" PH 2
28 107847-01 Screw, #619 x 1/4" 2
29 109157-01 Sensor Bracket 1
30 102445-01 Piezo Ignitor 1
31 107564-01 Remote Control 1
32 107562-01 Switch and Wire Assy 1
33 110111-01 Bracket, Switch
and Piezo 1
34 102334-01 Palnut Fastener 1
35 107573-01 Valve Bracket 1
36 107743-01 Thermocouple Tube 1
37 107559-01 Gas Control Valve
(Natural) 1
107559-02 Gas Control Valve
(Propane/LP) 1
38 107560-01 Magnetic Manual
Override Handle 1
39 110108-01 Burner Shield 1
40 098544-01 Wire Support Clip 1
41 101629-01 1.5" Bushing 2
PARTS LIST
REMOTE CONTROL LOG BASE ASSEMBLY MODELS
VTGF33PRB AND VTGF33NRB
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 31 of this manual.
KEY PART
NO. NUMBER
DESCRIPTION QTY.
** Not a field replacement part.
42 104015-01 Power Cord 1
43 110885-01 Inlet Tube 1
44 107568-01 Main Power Cable 1
45 110063-02 Burner, Front 1
46 111458-01 Burner Alignment
Bracket 1
47 099415-12 Pressure Regulator
(Natural) 1
099415-18 Pressure Regulator
(Propane/LP) 1
48 097809-03 Fitting 3/8" Flare to
1/2" NPT 1
49 101628-03 Flexible Connector 1
50 110884-01 Burner Tube 1
51 099056-27 Injector (Rear Burner)
Natural Gas 1
099056-29 Injector (Rear Burner)
Propane/LP Gas 1
52 101004-15 Injector (Front Burner)
Natural Gas 1
101004-18 Injector (Front Burner)
Propane/LP Gas 1
53 101004-11 Injector (Middle Burner)
Natural Gas 1
101004-18 Injector (Middle Burner)
Propane/LP Gas 1
54 110063-01 Middle Burner 1
55 108134-01 NG Rear Plate 1
56 108188-02 U-Drive Screw 1
57 099998-01 Fan Switch 1
58 101480-11 High Temp Black
Wire Assembly 1
59 099125-13 Terminal Board 1
60 099157-01 3-16 Break Mandrell
Rivet 1
PARTS AVAILABLE — NOT SHOWN
19724000 Cable Tie 4
901056-01 Flare Adapter Fitting,
3/8" NPT 1
107736-01 Wall Plate Assy Kit 1
(Contains Items
31, 33, 44)
107737-01 Wall Switch Assy Kit 1
(Contains Items
28, 30, 31, 33, 44)
107766-01 Battery, 12V, 23A
Remote 1
