Operating (nstructions and-Parts Manual
Typical Oversized Dust Bag Connection Diagrams for 3HP Models
OPTIONAL FOR
'A,
AND 2HP MODELS
NOTE: DUST BAG FOR 3HP MODEL MUST BE ORDERED WITH THE DUST COLLECTOR
Parts List for #HB-24X72 and #HB-48X72 Hanging Bags
Hanging
Bag
(HB)
Ref.
No:
Qty.
Description
For Dust Coilector Models
IHPtoSHP
Bag Type
#HB-24X72
#HB-48X72
•1
1
Ring, 24" Dia., 6 holes
27131
—
1
Ring, 48" Dia., 12 holes
—
27123
2
6
J Hooks with 1/4-20 nuts
A
—
12
J Hooks with 1/4-20 nuts
—
A
3
1
Dust Bag
Select from product catalog
4
3
Hose Clamps, 6“
31244
31244
5
1
Hose Connector, 6"
51088
51088
6
1
Hose. 6" dia. x 60* long
31626
31626
▲ Standard hardware store items available locally.
Ref. No. 4,5 & 6 are included with 3HP Model.
Parts List for «DB-24X36, #DB-24X72 and #DB-48X72 Drum Bags
Drum
Bag
(DB)
Ref.
No.
Qty.
Description
For Dust Collector Models
1/2 & 3/4HP
IHPtoSHP
Bag Type
#DB-24X36 »DB-24X72 »DB-48X72
1
1 .
Dust Bag
Select from product catalog.
2
1
Hose Connector, 4"
51086
—
—
1
Hose Connectgr, 6“
—
51088
51088
3
3
Hose Clamps, 4"
31379
—
—
3
Hose Clamps, 6*
—
31244
31244
4
1
Hose, 4" dia. x 60* long
31623
—
1
Hose, 6“ dia. x 60* long
—
31626
31626
2,3 & 4 (for 6" hose) are included with 3HP Model.
■drum
not included
I
4
