D-Link DSL-30B Quick Install Guide
Rear Panel View
LAN Port
Connect Ethernet devices
such as computers, switches,
and hubs.
ON/OFF
Press this button to
turn the unit on or off.
Power Receptor
Receptor for the supplied
power adapter.
DSL Line
Connect to an active
telephone line (RJ-11).
USB Port
Connect a computer
using a USB cable.
Reset
Pressing the Reset button
restores the modem to its original
factory default settings.
