Main components and
devices
Position on motorcycle
(fig. 37)
1) Fuel tank filler cap.
2) Seat lock.
3) Sidestand.
4) Rearview mirrors.
5) Front fork adjusters.
6) Rear shock absorber adjusters.
7) Suspension tie-rod for adjustment of rear ride height.
8) Exhaust silencer (see note on page 65).
9) Catalytic converter.
3
7
1
4
5
4
2
8
9
5
6
fig. 37
