Ducati 848 User Manual
Page 107
106
E
Wire colour coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Notes
The electrical system wiring diagram can be found at
the end of this manual.
Key to fusebox
(fig. 77 and fig. 79)
Pos.
Devices
Rating
1
Key-on
10 A
2
Lights
15 A
3
Devices
15 A
4
Instrument panel
5 A
5
Injection
20 A
6
Engine Electronic Control Unit
5 A
7
Fans
7.5 A
