DATALOGIC JET™
5
5 TECHNICAL FEATURES
5.1 TECHNICAL DATA
Datalogic Jet™ Common Features
Electrical Features
Power
DC supply 12 to 14 V ± 5%
Battery pack 2 cell Li-Ion 1070 mAh@ 7.4 V (nominal)
Large capacity pack 2 cell Li-Ion 1800 mAh@ 7.4 V (nominal)
Internal backup battery Rechargeable Li-Ion 30 mAh
Communication Features Windows CE COM Port
Bluetooth interface COM5
Serial interface RS232
USB 1.1 COM1
COM6
Wireless Features
WLAN IEEE 802.11b DSSS
WPAN Bluetooth® IEEE 802.15, Class 2, Version 1.2
WWAN GSM/GPRS Tri-band (900, 1800, 1900 MHz)
Radio with accessible SIM card interface
Hardware Features
FLASH 128 MB
DRAM 128 MB
Microprocessor Intel XScale PXA-270 520 MHz
Accessible card socket Mini SD
Audio Speaker, Microphone, Headset Jack
LED Two-color Programmable LED
Charging Status (two-color LED)
Bluetooth® (blue LED)
Display 64K Color TFT LCD with 320 x 240 pixel resolution, with
LED backlight and touch screen
Keyboard 25 Plastic Top Backlit Keys plus Power Button plus 2
Lateral Push-buttons
Environmental Features
Working temperature * -10° to + 50 °C / +14° to +122 °F
Storage temperature -20° to +70 °C / -4° to +158 °F
Humidity ** 90% non condensing for temperatures<40°C
Protection IP64
ESD protection
4 KV contact discharge, 8 KV air discharge
Drop resistance *** 1.5 m / 5 ft
* Close to the limits of the working temperature, some display and/or battery performance
degradation may occur.
** Multiple rapid humidity and/or temperature variations may cause condensing.
*** Multiple drops can permanently damage the device.
76
