7. Fine adjustment of vertical position
1. Loosen the screw on on the lower right side.
2. Turn the height adjusting screw to adjust the height.
3. After completing adjustments, retighten the
loosened screw.
Tightening torque: 0.98 N•m (10 kgf•cm)
Supplied Allen
wrench (I)
Note:
Do not loosen these three
screws.
•
Repeat steps 1 to 7 to fine adjust the image to the screen.
See page 22 for details on adjustment range.
A
A
B
B
Tightening torque: 0.98 N•m (10 kgf•cm)
