Dukane LCD Data Video Projector 8104HW-WALLARM - Manual (Page 10)

Screen center
Screen center
Screen thickness
Wall hole center
Amount of vertical adjustment
42,5
195
(1,67)
125 (4,92)
136 (5,35)
32 (1,26)
c3
a c2
85 (3,35)
240
c1
c4
b
30
30 (1,18)
(1,18)
(*1)
Screen center
8
16:10 screen
Base bracket attachment diagram
(Full screen: Reference value for 1,280 × 800 pixel image.)
Note:
The wall hole center is 42.5 mm (1.67 inches) to the right of the screen center.
Unit: mm (inches)
Unit: mm (inches)
a b c1 c2 c3 c4
mm (inches) mm (inches) mm (inches) mm (inches) mm (inches)
60 120 (4,7) 295 (11,6) 1102 (43,4) 202 (8,0) 410(16.1)
70 188 (7,4) 332 (13,1) 1274 (50,2) 239 (9,4) 447(17.6)
80 256 (10,1) 369 (14,5) 1446 (56,9) 276 (10,9) 484(19.1)
90 324 (12,8) 407 (16,0) 1618 (63,7) 314 (12,4) 522(20.1)
100 392 (15,4) 444 (17,5) 1791 (70,5) 351 (13,8) 559(22.0)
(8104HW)
Diagonal size (inches)
