Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General
Power supply
12 V DC
Current consumption max. 14 A
Maximum power output 50 W x 4 channels
Fuse 15 A
Dimensions (L x W x H) 178 x 165 x 50 mm
FM stereo radio
Frequency range
65.0 – 74.0/87.5 – 108.0 MHz
Usable sensitivity 15 dB
AM Section
Frequency range
522 kHz – 1620 kHz
Usable sensitivity 25 dB
Disc player
Usable disc:
CD/CD-R/CD-RW
Supported formats CDDA/MP3/WMA
Frequency characteristics: 20 Hz - 20 kHz ± 5 dB
Signal to noise ratio: 65 dB
Number of channels: 2 stereo
Line out
Output:
1 V
