Diamond-MM-48-AT User Manual V1.01 Page 6
J4: Relays and Optocouplers
Opto 0- 1 2 Opto 0+
Opto 1- 3 4 Opto 1+
Opto 2- 5 6 Opto 2+
Opto 3- 7 8 Opto 3+
No connection 9 10 No connection
Relay 0 NO 11 12 Relay 0 NC
Relay 0 C 13 14 Relay 1 NO
Relay 1 NC 15 16 Relay 1 C
Relay 2 NO 17 18 Relay 2 NC
Relay 2 C 19 20 Relay 3 NO
Relay 3 NC 21 22 Relay 3 C
Relay 4 NO 23 24 Relay 4 NC
Relay 4 C 25 26 Relay 5 NO
Relay 5 NC 27 28 Relay 5 C
Relay 6 NO 29 30 Relay 6 NC
Relay 6 C 31 32 Relay 7 NO
Relay 7 NC 33 34 Relay 7 C
Signal Name Definition
Relay output contacts:
Relay N C (N = 0 to 7) Relay output common contact; this contact is always
used with relay output connections.
Relay N NC Relay output normally connected contact; this contact is connected
to the Out N C contact when power is off or when a 0 is written to the
relay’s control bit in the relay control register, and it is disconnected
when power is on and a 1 is written to the relay’s control bit.
Relay N NO Relay output normally open contact; this contact is disconnected
when power is off or when a 0 is written to the relay’s control bit in
the relay control register, and it is connected to the Out N C contact
when power is on and a 1 is written to the relay’s control bit.
Optoisolated input contacts:
Opto N + (N = 0 to 3) Optoisolated input contact, high side
Opto N - Optoisolated input contact, low side; opto inputs are polarized
