Compex WP54AG User Manual
Page 196
185
Steady Green
Wireless interface up and running.
Ready for operation.
4
LED
(WLAN
Link/Act LED)
Flashing Green
Activity is detected in the wireless
network.
Steady Green
Connection has been established
between the device and the
network.
Flashing Green
Activity is detected in the network.
5
LED
(Port 1 & 2
LEDs)
Off
No network connection.
Back View of Access Point
Name
Description
6
External Antenna
SMA antenna
7
Ethernet Port 2
Connection for computer with NIC (Network
Interface Card) or Ethernet network card.
